What is the difference between Pipe and Tube ?

People use the words pipe and tube interchangeably, and they think that both are the same. However, there are significant differences between pipe and tube. The short answer is: A PIPE is a round tubular to distribute fluids and gases, designated by a nominal pipe size (NPS or DN) that represents a rough indication of the pipe conveyance capacity; a TUBE is a round, rectangular, squared or oval hollow section measured by outside diameter (OD) and wall thickness (WT), expressed in inches or millimeters.

Stainless Steel Pipes & Tubes Specifications

Dimensions : ASTM, ASME and API
Size : 6 NB to 2400 NB x SCH 5 to SCH XXS
Schedule : SCH5, SCH5S, SCH10, SCH10S, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / EFW / Welded / Fabricated / LSAW Pipes
Form : Seamless Pipes, ERW Pipe, EFW, Pipe, H-SAW Pipe, L-SAW Pipe, Seamless Tube, ERW Tube, Square Pipe, Rectangular Pipe
Length : Single Random, Double Random & Custom Cut Length
End : Plain End, Bevelled End, Threaded
Grades : ASTM A312 / A213 / A269 / A358 / A778 GR TP 201, 202, 301, 302, 304, 304L, 309, 310, 316, 316L, 316LN, 316Ti, 317L, 321, 347, 405, 409, 410, 420, 430, 440C, 904L, AL-6XN (N08367).

Material of Construction in Pipes & Tubes

  Alloy Steel Pipes & Tubes Specifications

Grade : ASTM A335 / A213 GR P11, P12, P22, P5, P9, P91, T11, T12, T22, T5, T9, T91.


  Carbon Steel Pipes & Tubes Specifications

Grade : ASTM A106 / A53 / A179 / A333 / A210 Gr. B, API 5L X42/X46/X52/X56/X60/X65/X70
PSL-1 / PSL-2, Gr, 3, 6, IS 1239, IS 3589, Boiler Tube – BS 3059 – Gr. 320,
360, Gr. A1, BS 6323.


  Duplex & Super Duplex Steel Pipes & Tubes Specifications

Grade : ASTM A789, A790, A928 GR 2205 (S31803 / S32205), SMO254 (S32154),
2507 (S32750 / S32760), Ferralium 255 (S32550), SMO 654 (S32654).


  Nickel Alloy Pipes & Tubes Specifications

Grade : ASTM B 161 ASME SB 161 / ASTM B729 ASME SB729 GR 200 (N02200), 201 (N02201),
Alloy 20 (N08020).


  Monel Alloy Pipes & Tubes Specifications

Grade : ASTM B165 ASME SB165 / ASTM B725 ASME SB725 GR 400 (N04400), 500 (N05500).


  Inconel Pipes & Tubes Specifications

Grade : ASTM B167, B444, B407, B423, B677 GR 600 (N06600), 601 (N06601), 625 (N06625),
718 (N07718), 800 (N08800), 800H (N08810), 800HT (N08811), – 825 (N08825),
904L (N08904).


  Copper Alloy Pipes & Tubes Specifications

Grade : ASTM B111 ASME SB111 / ASTM B466 ASME SB466 Commercial, ETP, OFE,
CuNi 90/10 (C70600), CuNi 70/30 (C71500), Brass, Naval Brass, Aluminium Bronze,
Admiralty Brass.


  Hastelloy Pipes & Tubes Specifications

Grade : ASTM B622 ASME SB622 / ASTM B619 ASME SB619 GR C726 (N10276), C4 (N06455),
C22 (N06022), C2000 (N06200), X (N06002), B2 (N10665), B3 (N10675).


  Titanium Pipes & Tubes Specifications

Grade: ASTM B338 / B861 / B862 GR 2, 5 (Ti6AI4V), 7.


  Aluminium Pipes & Tubes Specifications

Grade : 1100, 2014, 2024, 5052, 5083, 5454, 6061, 6063, 6101, 7075.
